SETMC3FXXS

Female 3-pin XLR connector with metal body, for a long life and high reliability.

Features:
Number of poles: 3.
Cable: Ø 3.5 - 8 mm.
Lifetime: >1000 cycles.
Locking system: latch lock.
Shell: die-cast Zinc casting.
Copper contacts, tinned.
Traction exhaust: Polyacetal.
Flammability class: UL 94 HB.
Compliance standards: IEC 61076-2-103.
Degree of protection: IP 40.
Solderability: complies with IEC 68-2-20.
Temperature range: -30 °C to +80 °C.
Dimensions (WxHxD): 72x21x21 mm.
